DWK Life Sciences (Kimble) Two-piece Vacuum Trap, 400 H x 160 mm W
Vacuum Trap, 400 H x 160 mm W, Plain, Borosilicate Glass, 250 H x 48 mm OD Body Below Joint, 20 mm OD Inner Tubing, 45/50 Standard Taper Joint, With 180° Connections, Two-piece Construction Allows Removal of Condensate
- Manufacturer Part No: 926300-0024
- SECO Part No: DWK-926300-0024
- Sold As:
-
Availability:
Login to View Your Price
-
List Price :
| Height | : | 400 mm |
| Body Height | : | 250 mm Below Joint |
| Body Diameter | : | 48 mm OD Below Joint |
| Inner Tubing Diameter | : | 20 mm OD |
| Material | : | Borosilicate Glass |
| Width | : | 160 mm |
| Standard Taper Joint | : | 45/50 |
- This trap protects the mechanical pump from attack by corrosive vapors which can be condensed by using liquid nitrogen or dry ice/slurry mixtures
- Outlets are 180° apart for easy installation into a variety of vacuum systems
- Two-piece construction allows removal of condensate
- Connectors of 926035 series are barbed and fit 0.5" ID flexible tubing
- Connectors of 926300 series are plain
- Manufactured from 33 expansion, low extractable borosilicate glass conforming to USP type I and ASTM E438, type I, class A requirements
