Labconco Basic™ 47 Explosion-proof Benchtop Laboratory Hood, 53 H x 47 W x 25" D
Laboratory Hood, 53 H x 47 W x 25" D, Glacier White, Powder-coated 16 ga Steel, 115 V, 60 Hz, 7.8 A, Single Phase Electrical Requirements, 4' Nominal Width, Basic™ 45 Model, Explosion-proof Type, Benchtop, 10.3" ID Exhaust Connection
- Manufacturer Part No: 2247500
- SECO Part No: 80-2257-01
- Sold As:
-
Availability:
Login to View Your Price
-
List Price :
Basic laboratory hoods are designed specifically for laboratories, classrooms and light duty applications where safe ventilation is required. Constructed of powder-coated steel, Basic hoods are economical and have a smaller overall height and depth than traditional hoods so they fit in areas with low ceilings or narrow aisles.
| Height | : | 53" |
| Width | : | 47" |
| Depth | : | 25" |
| Color | : | Glacier White |
| Material | : | 16 ga Steel |
| Finish | : | Powder-coated |
| Voltage | : | 115 V |
| Hertz | : | 60 Hz |
| Amperage | : | 7.8 A |
| Phase | : | Single |
| Nominal Width | : | 4' |
| Lighting | : | Incandescent |
| Model | : | Basic 47 |
| Type | : | Explosion-proof |
| Style | : | Benchtop |
| Pressure | : | 720 cfm |
| Motor HP | : | 1/2 Hp |
| Exhaust Connection | : | 10.3" ID |
| Blower | : | Integral Explosion-proof Blower |
| Includes | : | Integral Explosion-proof Blower |
- By-pass airflow design
- Durable glacier white powder-coated 16 ga steel exterior and interior resists chemical exposure
- Vertical-rising tempered safety glass sash
- Adjustable two-piece baffle
- Curved air foil that lifts off for cleaning
- Removable front panel for access to electrical wiring
- Right side fixture panel is factory-prepared to accept up to three service fixtures, one electrical duplex and one airflow monitor
- Right interior wall factory-prepared for one cupsink and turret
- Powder-coated steel 10.3" OD exhaust connection
- Explosion-proof incandescent light fixture (requires installation; bulb not included)
- Furnished without switches and wiring as these must conform to local codes
- Belt-driven blower with adjustable sheave
- Powder-coated steel base and housing
- Corrosion-resistant coated steel impeller
- Approved by ASHRAE 110, ASTM E84, CAN/CSA C22.2, NFPA 45, SEFA 1, UL, ETL
