Spectrosil® 18/9-Q-10
Share
  1. pin-int
Email Print

Spectrosil® Quartz Micro Spectrophotometer Cell, 10 mm Path Length

Micro Spectrophotometer Cell, 10 mm Path Length, 12.5 L x 12.5 W x 45 mm H Exterior, 10 L x 2 mm W Interior, Quartz, Rectangular, 9 mm Base Thickness, 0.580 ml Nominal Volume, 2 Polished Windows, 170 to 2700 nm Range

  • Manufacturer Part No: 18/9-Q-10
  • SECO Part No: 18/9-Q-10
  • Sold As:
  • Availability: loading

Micro cells, type 18, with a 2 mm internal width are for use with sample volumes smaller than the standard rectangular or Semi-Micro cells. The nominal working volume of this range represents only 20% of the standard rectangular cells Type 1 with the same path length. Micro cells are available with either clear walls or black walls which are opaque and improve sensitivity. The cells have an exterior height of 45 mm. Each cell has an open top and is supplied with a PTFE cover (not pictured with the Type 18B or 18B9). Smaller sample volumes can be achieved by using cell Type 18/9 or 18B9 with a 9 mm instead of a 3 mm thick base.

Material : Quartz
Shape : Rectangular
Path Length : 10 mm
For Use With : For Spectrophotometers
Length : 12.5 mm Exterior, 10 mm Interior
Width : 12.5 mm Exterior, 2 mm Interior
Exterior Height : 45 mm
Thickness : 9 mm Base
Type : Micro
Range : 170 to 2700 nm
Nominal Volume : 0.580 ml
Number Polished Window : 2
Cell Top : Open
  • Physical configuration: Walls parallel to the light path thickened, sample chamber is 2 mm wide
  • Primary use: Absorbtion measurement using reduced volume
  • Instrument: Designed for use with spectrophotometers
  • Cell top: Open top, supplied with a non-sealing PTFE cover
  • Usage note: Thick base (18/9) can not be used with instruments having a Z dimension of 8.5 mm
