Microfiber Filter, Grade GF/D, 7 mm dia, Circle, Borosilicate Glass
Microfiber Filter, Grade GF/D, 7 mm dia, Circle, Borosilicate Glass, 2.7 µm Particle Retention in Liquid, 675 µm Thickness, 681 ml/min Water Flow Rate, 2.6 s/100 ml/in2 Air Flow Rate, 121 g/m2 Basis Weight, 41 s/ml Filtration Speed, Binder-free
- Manufacturer Part No: 1823-007
- SECO Part No: GEH-1823-007
- Sold As:
-
Availability:
Login to View Your Price
-
List Price :
Cytiva's Whatman™ Grade GF/D fine membrane filters are thick and offer good loading capacity. GF/D can also function as a prefilter when used with GF/B, and it comes in many sizes to fit most filter holders.
| Diameter | : | 7 mm |
| Grade | : | Grade GF/D |
| Material | : | Borosilicate Glass |
| Binder Type | : | Binder-free |
| Maximum Temperature | : | 550°C |
| Nominal Air Flow Rate | : | 2.6 sec/100 ml/in2 |
| Nominal Basis Weight | : | 121 g/m2 |
| Particle Retention in Liquid | : | 2.7 µm |
| Shape | : | Circle |
| Thickness | : | 675 µm |
| Typical Water Flow Rate | : | 681 ml/min |
| Wet Burst Pressure | : | 3.2 kPa |
| Filtration Speed | : | 41 sec/ml |
| Loading Capacity | : | VH |
| Type | : | Hyperfilm ECL Film |
Highly suitable for use in applications involving air filtration and for gravimetric analysis of volatile materials where ignition is involved, because of the low resistance it is recommended for fluid flow and high particle loading capacityThick filter media for increased loading capacityNominal particle retention of 2.7 µmCan be used as a fine membrane prefilterPrefilter
